NO.

Part Name

CS to ASTM

AS to ASTM

SS to ASTM

Type A105

Type F22

Type F304(L)

Type F316(L)

1

Body

A105

A182 F22

A182 F304(L)

A182 F316(L)

2

Disc

A276 420

A276 304

A276 304(L)

A276 316(L)

3

Stem

A182 F6

A182 F304

A182 F304(L)

A182 F316(L)

4

Gasket

Corrugated SS + graphite

SS + PTFE

5

Bonnet

A105

A276 304

A276 304(L)

A276 316(L)

6

Bonnet Bolt

A193 B7

A193 B16

A193 B8

A193 B8M

7

Stem Packing

Flexible Graphite

PTFE

8

Gland

A276 410

A182 F304(L)

A182 F316(L)

9

Gland Flange

A216 WCB

A351 CF8

10

Handwheel

A197

11

Nameplate

SS

12

H.W.Nut

A194 2H

A194 4

A194 8

A194 8M

13

Yoke Nut

A276 410

14

Gland Nut

A194 2H

A194 4

A194 8

A194 8M

15

Gland Eyebolt

A193 B7

A193 B16

A193 B8

A193 B8M

16

Pin

A276 420

A276 304

Suitable Medium

W.O.G.etc

W.O.G.etc

HNO3,CH3OOH etc

Suitable Temperature

-29~425

-29~550

-29~180

NPS

1/2"

3/4"

1"

1-1/4"

1-1/2"

2"

L

98

111

120

140

140

170

H(OPEN)

175

215

254

305

305

365

W

100

125

160

160

180

200

Weights

5

6.3

7.6

9.8

13.8

14.0
