Design and Manufacture: API 608,API 6D,BS5351
Face to face(end to end): ANSI B16.10,API 6D
Flanged connection:2"~24" to ANSI B16.5
Fire-safe: API 607,API 6FA
Butt welded end: ANSI B16.25
Test and inspection: API 598,API 6D
Usage
Way ball valve with T-shaped and L-shaped. T-shaped pipe to make three orthogonal interconnected and cut off the third channel, divert traffic, merging effect. L-shaped connecting only two orthogonal channels, can not maintain a third pipe connected with each other only as a distribution function.
Features
1, three-valve integrated in the structure of a structure, 4 seat sealing surface type, flange connection, high reliability, design and implementation of the lightweight.
2, three core sub-T-ball and L-shaped, long life, flow capacity, small resistance.
3, valve-action points by single and double acting two types, single-action feature is that once the power source fails, the ball will be in the state of the control system requirements.
Specifications
|
Material |
WCB |
CF8 |
||||
|
Pressure(Mpa) |
1.6 |
2.5 |
4.0 |
1.6 |
2.5 |
4.0 |
|
Temperature(oC) |
<150 |
|||||
|
Medium |
Water, steam, oil, etc. |
Weak corrosive media |
||||
|
Body |
Carbon steel castings |
Chrome-nickel-titanium steel casting |
||||
|
Ball, Stem |
2Cr13 |
Chrome-nickel stainless steel titanium |
||||
|
Seat |
RPTFE |
|||||
|
Packing |
PTFE |
|||||
|
|
|
|
|
|
|
|
Main connection dimensions
|
DN |
L |
D |
D1 |
D2 |
b |
Z-d |
H |
W |
|
15 |
108 |
95 |
65 |
45 |
14 |
414 |
95 |
140 |
|
20 |
117 |
105 |
75 |
55 |
14 |
414 |
105 |
160 |
|
25 |
127 |
115 |
85 |
65 |
14 |
414 |
113 |
180 |
|
32 |
140 |
135 |
100 |
78 |
16 |
418 |
135 |
250 |
|
40 |
165 |
145 |
110 |
85 |
16 |
418 |
142 |
300 |
|
50 |
178 |
160 |
125 |
100 |
16 |
418 |
154 |
350 |
|
65 |
191 |
180 |
145 |
120 |
18 |
418 |
175 |
350 |
|
80 |
203 |
195 |
160 |
135 |
20 |
818 |
190 |
400 |
|
100 |
229 |
215 |
180 |
155 |
20 |
818 |
225 |
500 |
|
125 |
356 |
245 |
210 |
185 |
22 |
818 |
245 |
600 |
|
150 |
394 |
280 |
240 |
210 |
24 |
823 |
265 |
800 |
|
200 |
457 |
335 |
295 |
265 |
26 |
1223 |
305 |
800 |
|
250 |
533 |
405 |
355 |
320 |
30 |
1225 |
370 |
1300 |
