Product Info:

Products Name: Side-mounted bore eccentric seml-ball valve

Product Catalog: Ball Valve

OnLine Service:

Print this Page	Bookmark this
Skype Online	E-mail Us
Live Messenger	PDF Download

【Prev Products】	【Next Products】

Description	Send Inquiry

Side mounted bore eccentric semi-ball valve main connection and figue dimension(mm):

PN(MM)	DN(MM)	L	D	K	d	H			f	b	Z-do
PN(MM)	DN(MM)	L	D	K	d	handle	pneumatic	hydraulic	f	b	Z-do
1.0MPA	50	108	160	125	99	350	625	530	2	18	4-18
	65	112	180	145	120	370	625	530	2	18	4-18
	80	114	200	160	132	380	645	565	2	20	8-18
	100	127	220	180	156	420	675	600	2	22	8-18
	125	140	250	210	184	460	715	640	2	24	8-18
	150	140	285	240	211	555	800	705	2	24	8-22
	200	152	340	295	266	760	850	775	2	26	8-22
	250	165	395	350	319	830	925	945	2	26	12-22
	300	178	445	400	370	900	1050	1080	2	26	12-22
	350	190	505	460	429	970	1100	1170	2	26	16-22
	400	216	565	515	480	1210	1210	1230	2	28	16-26
	450	222	615	565	530	1270	1265	1380	2	28	20-26
	500	229	670	620	582	1355	1310	1450	2	28	20-26
	600	267	780	725	682	1380	1455	1605	2	30	20-30
	700	292	895	840	794	1550	1585	1860	5	30	24-30
	800	318	1015	950	901	1760	1750	2080	5	32	24-33
	900	330	1115	1050	1001	1865	1980	2260	5	34	28-33
	1000	410	1230	1160	1112	1980	2030	2400	5	34	28-36
	1200	470	1455	1380	1328	2260	2260	2650	5	38	32-39
	1400	530	1675	1590	1530	2480	2590	2870	5	48	36-42
	1600	600	1915	1820	1750	2800	2780	3200	5	52	40-48
	1800	670	2115	2020	1950	3050	3000	3450	5	56	44-48
	2000	760	2325	2230	2150	3300	3400	3700	5	60	48-48

PN(MM)	DN(MM)	L	D	K	d	H			f	b	Z-do
PN(MM)	DN(MM)	L	D	K	d	handle	pneumatic	hydraulic	f	b	Z-do
1.6MPA	50	108	160	125	99	350	625	530	2	18	4-14
	65	112	180	145	120	370	625	530	2	18	4-14
	80	114	200	160	132	380	645	565	2	20	8-18
	100	127	220	180	156	420	675	600	2	22	8-18
	125	140	250	210	184	460	715	640	2	22	8-18
	150	140	285	240	211	555	800	705	2	24	8-22
	200	152	340	295	266	760	850	775	2	24	12-22
	250	165	405	350	319	830	925	945	2	26	12-26
	300	178	460	400	370	900	1050	1080	2	28	12-26
	350	190	520	460	429	970	1100	1170	2	30	16-26
	400	216	580	515	480	1210	1210	1230	2	32	16-30
	450	222	640	565	530	1270	1265	1380	2	34	20-30
	500	229	715	620	582	1355	1310	1450	2	36	20-33
	600	267	840	725	682	1380	1455	1605	2	38	20-36
	700	292	910	840	794	1550	1585	1860	5	38	24-36
	800	318	1025	950	901	1760	1750	2080	5	38	24-39
	900	330	1125	1050	1001	1865	1980	2260	5	40	28-39
	1000	410	1255	1160	1112	1980	2030	2400	5	42	28-42
	1200	470	1485	1380	1328	2260	2260	2650	5	48	32-48
	1400	530	1685	1590	1530	2480	2590	2870	5	48	36-48
	1600	600	1930	1820	1750	2800	2780	3200	5	55	40-52
	1800	670	2130	2020	1950	3050	3000	3450	5	55	44-52
	2000	760	2345	2230	2150	3300	3400	3700	5	60	48-56
