NO.

Part Name

CS to ASTM

AS to ASTM

SS to ASTM

Type A105

Type F22

Type F304(L)

Type F316(L)

1

Body

A105

A182 F22

A182 F304(L)

A182 F316(L)

2

Disc

A276 420

A276 304

A276 304(L)

A276 316(L)

3

Stem

A182 F6

A182 F304

A182 F304(L)

A182 F316(L)

4

Gasket

Corrugated SS + graphite

SS + PTFE

5

Bonnet

A105

A276 304

A276 304(L)

A276 316(L)

6

Bonnet Bolt

A193 B7

A193 B16

A193 B8

A193 B8M

7

Pin

A276 420

A276 304

8

Gland

A276 410

A182 F304(L)

A182 F316(L)

9

Gland Eyebolt

A193 B7

A193 B16

A193 B8

A193 B8M

10

Gland Flange

A216 WCB

A351 CF8

11

Gland Nut

A194 2H

A194 4

A194 8

A194 8M

12

Yoke Nut

A276 410

13

H.W.Nut

A194 2H

A194 4

A194 8

A194 8M

14

Nameplate

SS

15

Handwheel

A197

16

Stem Packing

Flexible Graphite

PTFE

Suitable Medium

W.O.G.etc

W.O.G.etc

HNO3CH3OOH etc

Sutiable Temperature

-29~425

-29~550

-29~180

NPS

Conv.

3/8"

1/2"

3/4"

1"

1-1/4"

1-1/2"

2"

Full

3/8"

1/2"

3/4"

1"

1-1/4"

1-1/2"

2"

L

79

79

92

111

120

152

172

200

H(OPEN)

166

166

171

207

240

258

330

355

W

100

100

100

125

160

160

180

200

Weights

Bolted

1.9

1.9

2.1

3.5

6.0

7.5

11.4

14.6

Welded

1.7

1.7

1.9

3.3

5.2

6.8

10.6

13.8

NPS

Conv.

3/8"

1/2"

3/4"

1"

1-1/4"

1-1/2"

2"

Full

3/8"

1/2"

3/4"

1"

1-1/4"

1-1/2"

2"

L

92

111

111

120

152

172

200

220

H(OPEN)

171

207

207

240

258

330

355

370

W

100

125

125

160

160

180

200

240

Weights

Bolted

2.2

3.7

3.6

6.8

7.6

11.6

15.0

21.9

Welded

2.0

3.4

3.3

6.0

5.6

10.3

14.2

18.0
