Standard Material Specifications
|
NO. |
Part Name |
CS to ASTM |
AS to ASTM |
SS to ASTM |
|
|
Type A105 |
Type F22 |
Type F304(L) |
Type F316(L) |
||
|
1 |
Body |
A105 |
A182 F22 |
A182 F304(L) |
A182 F316(L) |
|
2 |
Gasket |
Corrugated SS + graphite |
SS + PTFE |
||
|
3 |
Bonnet Bolt |
A193 B7 |
A193 B16 |
A193 B8 |
A193 B8M |
|
4 |
Pin |
A276 420 |
A276 304 |
||
|
5 |
Gland |
A276 410 |
A182 F304(L) |
A182 F316(L) |
|
|
6 |
Gland Eyebolt |
A193 B7 |
A193 B16 |
A193 B8 |
A193 B8M |
|
7 |
Gland Nut |
A194 2H |
A194 4 |
A194 8 |
A194 8M |
|
8 |
Yoke Nut |
A276 410 |
|||
|
9 |
H.W.Nut |
A194 2H |
A194 4 |
A194 8 |
A194 8M |
|
10 |
Nameplate |
SS |
|||
|
11 |
Handwheel |
A197 |
|||
|
12 |
Gland Flange |
A216 WCB |
A351 CF8 |
||
|
13 |
Stem Packing |
Flexible Graphite |
PTFE |
||
|
14 |
Bonnet |
A105 |
A276 304 |
A182 F304(L) |
A182 F316(L) |
|
15 |
Stem |
A182 F6 |
A182 F304 |
A182 F304(L) |
A182 F316(L) |
|
16 |
Disc |
A276 420 |
A276 304 |
A276 304(L) |
A273 316(L) |
|
Suitable Medium |
W.O.G.etc |
W.O.G.etc |
HNO3,CH3OOH etc |
||
|
Suitable Temperature |
-29~425 |
-29~550 |
-29~180 |
||
Note: Other materials are available upon request.
Dimensions (mm) and Weights (Kg) 150Lb~600Lb
|
NPS |
1/2" |
3/4" |
1" |
1-1/4" |
1-1/2" |
2" |
||
|
L(RF)L1(BW) |
150 |
108 |
117 |
127 |
140 |
165 |
203 |
|
|
300 |
152 |
178 |
203 |
216 |
229 |
267 |
||
|
600 |
165 |
190 |
216 |
229 |
241 |
292 |
||
|
H(OPEN) |
150,300 |
166 |
171 |
207 |
240 |
258 |
330 |
|
|
600 |
171 |
207 |
240 |
258 |
330 |
380 |
||
|
W |
100 |
100 |
125 |
160 |
160 |
180 |
||
|
Weights |
150 |
RF |
4.5 |
6.9 |
9.8 |
13.5 |
19.5 |
28.0 |
|
BW |
2.3 |
3.6 |
7.8 |
8.2 |
12.0 |
15.0 |
||
|
300 |
RF |
4.8 |
7.7 |
11.0 |
16.8 |
21.2 |
32.6 |
|
|
BW |
2.8 |
4.0 |
8.5 |
9.2 |
12.6 |
16.8 |
||
|
600 |
RF |
5.6 |
7.8 |
12.5 |
17.0 |
23.5 |
38.8 |
|
|
BW |
3.4 |
4.7 |
9.2 |
10.5 |
13.3 |
18.9 |
||
Dimensions (mm) and Weights (Kg) 900Lb~1500Lb
|
NPS |
1/2" |
3/4" |
1" |
3/4" |
1-1/2" |
2" |
|
|
L(RTJ) |
900,1500 |
216 |
229 |
254 |
279 |
305 |
371 |
|
L1(BW) |
900,1500 |
216 |
229 |
254 |
279 |
305 |
368 |
|
H(OPEN) |
207 |
207 |
240 |
258 |
330 |
355 |
|
|
W |
125 |
125 |
160 |
160 |
180 |
200 |
|
|
Weights |
RTJ |
8.0 |
13.2 |
17.4 |
19.0 |
24.5 |
31.0 |
|
BW |
5.2 |
10.0 |
14.6 |
15.8 |
20.5 |
27.8 |
|
