The Specific Connection Code
|
Connection Code |
K |
K1 |
K2 |
K3 |
|
Screwed Weld |
Inclined End |
A Full Strength End |
Socket Weld End |
Standard Material Specifications
|
NO. |
Part Name |
CS to ASTM |
AS to ASTM |
SS to ASTM |
|
|
Type A105 |
Type F22 |
Type F304(L) |
Type F316(L) |
||
|
1 |
Body |
A105 |
A182 F22 |
A182 F304(L) |
A182 F316(L) |
|
2 |
Seat Ring |
A276 420 |
A276 304 |
A276 304(L) |
A276 316(L) |
|
3 |
Wedge |
A276 410 & 403 |
A182 F304 |
A182 F304(L) |
A182 F316(L) |
|
4 |
Gasket |
Corrugated SS + graphite |
SS + PTFE |
||
|
5 |
Stem |
A182 F6 |
A182 F304 |
A182 F304(L) |
A182 F316(L) |
|
6 |
Bonnet Bolt |
A193 B7 |
A193 B16 |
A193 B8 |
A193 B8M |
|
7 |
Pin |
A276 420 |
A276 304 |
||
|
8 |
Gland Eyebolt |
A193 B7 |
A193 B16 |
A193 B8 |
A193 B8M |
|
9 |
Gland Nut |
A194 2H |
A194 4 |
A194 8 |
A194 8M |
|
10 |
Nameplate |
SS |
|||
|
11 |
Handwheel |
A197 |
|||
|
12 |
H.W.Lock Nut |
A194 2H |
A194 4 |
A194 8 |
A194 8M |
|
13 |
Yoke Nut |
A276 420 |
|||
|
14 |
Gland Flange |
A105 |
A182 F11 |
A182 F304(L) |
A182 F316(L) |
|
15 |
Gland |
A276 410 |
A182 F304(L) |
A182 F316(L) |
|
|
16 |
Stem Packing |
Flexible Graphite |
PTFE |
||
|
17 |
Bonnet |
A105 |
A182 F22 |
A182 F304(L) |
A182 F316(L) |
|
Suitable Medium |
W.O.G.etc |
W.O.G.etc |
HNO3CH3OOH etc |
||
|
Suitable Temperature |
-29~425 |
-29~550 |
-29~180 |
||
Note: Other materials are available upon request.
